HP Envy x360 13.3 AMD Ryzen 5 7530U Pen Not Working Fix Windows 11

The stylus pen on your HP Envy x360 13.3 AMD Ryzen 5 7530U is not working – pen input is not detected when touching the display, the pen cursor does not appear, or side buttons on the pen produce no function. HP pen driver updates and Windows Ink configuration restore pen functionality on the HP Envy x360 13.3 AMD.

This guide covers HP MPP pen driver installation, Windows Ink settings, and pen pairing for the HP Envy x360 13.3 AMD Ryzen 5 7530U in Windows 11.

“HP Envy x360 13.3 AMD pen stopped working after Windows update. HP Support Assistant had Goodix pen digitizer driver update. After installing, pen recognized immediately and side button customization worked. Driver update was the only fix needed.” – Aizzuddin, student from Johor Bahru

Why Pen Does Not Work on HP Envy x360 13.3 AMD

The HP Envy x360 13.3 AMD pen digitizer uses a Goodix or ELAN MPP (Microsoft Pen Protocol) pen controller that requires a specific driver for Windows to recognize pen input separately from touch input. After Windows Update, the MPP pen driver can be replaced by a generic HID tablet driver that does not support MPP pressure levels, tilt detection, or side button mapping. Without the correct MPP pen driver, the pen may produce no input at all or only register as a finger touch without pressure sensitivity, appearing as if the pen is not working for drawing or note-taking applications.

• Goodix or ELAN MPP pen driver replaced by generic HID tablet driver after Windows Update
• HP Active Pen battery dead – pen produces no electromagnetic signal for digitizer to detect
• Windows Ink Workspace pen settings misconfigured after driver update
• Pen nib worn – physical tip deformed preventing consistent digitizer contact signal

Fix 1 – Update HP Pen Driver via HP Support Assistant

Open HP Support Assistant and check for Goodix Stylus, ELAN Pen, or HP Active Stylus driver updates. Install and restart. After restart, touch the HP Active Pen to the display – a cursor should appear at the pen tip position. Test pressure sensitivity by drawing in MS Paint or OneNote – varying pen pressure should produce different line widths in applications supporting pressure levels. If the pen cursor appears and follows the pen correctly, the driver update resolved the pen detection issue. Also verify side button functions in Settings – Bluetooth and devices – Pen and Windows Ink for button customization.

Fix 2 – Check HP Active Pen Battery

The HP Active Pen for Envy x360 13.3 AMD uses a AAAA battery (or rechargeable depending on model). If the pen LED does not light when clicking the top button, the battery may be depleted. For AAAA battery pens, unscrew the pen barrel top cap and replace the AAAA battery. For rechargeable HP pens, charge by inserting the tip into the magnetic charging connector or USB-C port on the pen. A depleted pen battery produces no digitizer signal, making the pen completely unresponsive to the touchscreen even with correct driver installed. After replacing or charging, touch the pen tip to screen – a functional pen with charged battery responds immediately.

Configure Windows Ink Pen Settings

Go to Settings – Bluetooth and devices – Pen and Windows Ink. Verify pen-related settings are enabled. Check that Write with your fingertip is off to prevent finger touch from interfering with pen input. In the Pen and Windows Ink settings, test the pen tip and eraser functions using the test areas. These settings also control press and hold for right-click behavior and pen button mapping. After driver update, Windows Ink settings sometimes need to be reconfigured as the new driver may reset pen button assignments to default values rather than preserving the previous user-configured button mapping.

Fix 3 – Check Pen in Device Manager

Open Device Manager – Human Interface Devices. Look for Goodix Stylus, ELAN WacomTablet, or HID-compliant pen entries. If missing or with warning icon, right-click and select Update driver. A working pen shows at least one pen-specific HID device in Device Manager that appears when the pen tip is brought close to the screen (within hover range) and disappears when the pen is moved away. If no pen device appears even within close proximity (1-2cm) of the screen, the pen hardware is not transmitting or the digitizer is not receiving – check pen battery before concluding driver issue on the HP Envy x360 13.3 AMD.

Fix 4 – Replace Pen Nib

HP Active Pen nibs (the replaceable plastic tips) wear down over time and can lose their shape, preventing consistent electromagnetic signal reception at the digitizer. HP includes replacement nibs with the HP Active Pen and additional nibs are sold separately. To replace: grip the worn nib with the nib removal tool (plastic clip included with pen) or flat edge tweezers, pull straight out. Insert new nib straight into the pen barrel until it clicks. A fresh nib provides consistent digitizer contact for reliable pen tracking and pressure sensitivity response on the HP Envy x360 13.3 AMD display.

Frequently Asked Questions

Why is pen not working on HP Envy x360 13.3 AMD Ryzen 5 7530U?

Goodix or ELAN MPP pen driver replaced by generic driver. Update via HP Support Assistant. Check pen battery – AAAA battery or rechargeable depending on HP Active Pen model.

How do I pair HP pen with HP Envy x360 13.3 AMD?

Basic input: no pairing needed, touch pen to screen. For side button customization: Settings – Bluetooth – Add device – hold pen button until LED flashes for Bluetooth pairing.

What pen works with HP Envy x360 13.3 AMD Ryzen 5 7530U?

MPP 2.0 compatible pens: HP Active Pen G3 (recommended), Wacom Bamboo Ink Plus, Microsoft Surface Pen. Non-MPP pens do not work.

Why does HP Envy x360 pen only draw lines and not erase?

Eraser function requires HP MPP pen driver update from HP Support Assistant. Eraser uses top barrel button or physical tail eraser – update driver to enable full eraser protocol support.

Conclusion

HP Envy x360 13.3 AMD Ryzen 5 7530U pen not working in Windows 11 is resolved by updating the Goodix or ELAN MPP pen digitizer driver from HP Support Assistant and checking HP Active Pen battery charge. Windows Pen and Windows Ink settings reconfiguration after driver update restores pen button mapping and hover distance settings. Device Manager pen HID device presence test distinguishes driver issues from pen battery or hardware signal absence. Pen nib replacement restores consistent electromagnetic digitizer contact for reliable pen tracking after nib wear reduces input reliability on the HP Envy x360 13.3 AMD display.
