Lenovo ThinkPad X13 Gen 5 AMD Ryzen 7 PRO 8840U — USB-C Thunderbolt 4 Not Detected Fix
The ThinkPad X13 Gen 5 AMD implements Thunderbolt 4 through AMD USB4, not Intel Thunderbolt silicon. This is an important distinction because the USB4 controller is part of the Ryzen 7 PRO 8840U itself, and firmware and driver updates behave differently from Intel-based systems. When Thunderbolt 4 docks, displays, or storage devices are not detected, the fixes below address the most common causes in order of likelihood.
Fix 1 — Update the AMD USB4 Controller Driver
The AMD USB4 controller that provides Thunderbolt 4 on the Ryzen 8000 PRO series is updated through the AMD Chipset driver package, not a separate Thunderbolt firmware utility. Download the latest AMD Chipset Driver from amd.com/support and install it. This package updates the USB4 host controller, the AMD GPIO controller, and the platform management interface all at once.
After installation, open Device Manager and expand Universal Serial Bus controllers. You should see AMD USB4 Host Router listed. If it shows a yellow warning icon, right-click it and choose Update driver → Search automatically for updated drivers.
Fix 2 — Enable USB4 / Thunderbolt in BIOS
Restart the laptop and press F1 to enter ThinkPad Setup (BIOS). Navigate to Config → Thunderbolt 4. Ensure the following settings are configured correctly:
- Thunderbolt 4 Controller: Enabled
- Security Level: No Security (for testing) or User Authorization (for production use)
- Pre-Boot ACL: On — required for pre-OS device access
- Allow USB devices: Enabled
On ThinkPad units managed by enterprise IT, some of these settings may be locked by a Supervisor password or remote BIOS policy. Contact your IT department if the BIOS settings are greyed out.
Fix 3 — Update Lenovo System Firmware
Open the Lenovo Vantage app and check System Update for pending firmware updates. Lenovo releases both BIOS updates and AMD PSP (Platform Security Processor) firmware updates that directly affect USB4 and Thunderbolt 4 device enumeration. Firmware updates for the X13 Gen 5 AMD have included fixes for Thunderbolt dock hot-plug reliability and USB4 tunneling at 40 Gbps.
If Lenovo Vantage is not installed, download the latest BIOS directly from support.lenovo.com using your laptop machine type (MTM number printed on the base of the unit).
Fix 4 — Test with a Thunderbolt 4 Certified Cable
Not all USB-C cables support Thunderbolt 4 speeds. A cable that works for USB 3.2 charging may silently fall back to USB 2.0 speeds when a Thunderbolt device is connected, causing the device to appear undetected or not function correctly. Confirm your cable carries the Thunderbolt 4 certification mark. Cables certified for Thunderbolt 4 support 40 Gbps data transfer and 100 W power delivery.
“My ThinkPad X13 Gen 5 AMD would not recognize my Thunderbolt dock at all. Updating the AMD Chipset Driver was all it took — the dock appeared immediately after the restart and has worked reliably ever since.”
— Hafizuddin Rosli, network engineer, Shah Alam
AMD USB4 vs Intel Thunderbolt — Key Differences
Unlike Intel-based ThinkPads that use a dedicated Intel Thunderbolt controller chip requiring Thunderbolt software and NVM firmware updates, the X13 Gen 5 AMD routes Thunderbolt 4 natively through the Ryzen PRO SoC. There is no separate Thunderbolt software to install. All management is done through the AMD Chipset driver and the BIOS Thunderbolt settings. If a third-party Thunderbolt software tool does not recognize your X13 Gen 5 AMD, this is expected behavior and not an error.
Ryan holds a Computer Science degree and has spent over 15 years troubleshooting Windows hardware and driver issues across major laptop brands. He writes practical, step-by-step guides for everyday users at softwaredriverdownload.com.
Frequently Asked Questions
Does the ThinkPad X13 Gen 5 AMD support Intel Thunderbolt devices?
Yes. AMD USB4 is fully compatible with Intel Thunderbolt 4 and Thunderbolt 3 devices including docks, external GPUs, storage arrays, and displays. The AMD USB4 controller implements the full Thunderbolt 4 specification including 40 Gbps bandwidth, daisy-chaining, and USB Power Delivery up to 100 W.
Why is there no Thunderbolt software in Lenovo Vantage for this model?
Intel Thunderbolt devices require Intel Thunderbolt software for device authorization and NVM firmware management. The ThinkPad X13 Gen 5 AMD uses AMD USB4 natively in the processor, which does not use Intel Thunderbolt software. Device authorization is handled entirely through the BIOS Security Level setting under Config → Thunderbolt 4.
My Thunderbolt dock works for USB but not for video output. What is wrong?
Video output over Thunderbolt on the X13 Gen 5 AMD requires DisplayPort tunneling to be enabled in BIOS under the Thunderbolt 4 settings. Also confirm the dock firmware is up to date using the dock manufacturer utility. Some older dock firmware versions do not correctly negotiate DisplayPort Alt Mode with AMD USB4 controllers.
Thunderbolt stops working after the laptop resumes from sleep. How do I fix this?
Go to Device Manager, right-click the AMD USB4 Host Router, select Properties → Power Management, and uncheck “Allow the computer to turn off this device to save power.” Also go to Settings → System → Power & sleep → Additional power settings and set USB selective suspend to Disabled in the current power plan.
